Description

Cosworth Connecting Rod Bearing Set Mitsubishi Evo 4G63 20002722

Engine bearings are one of the most vital components within an engine and are often overlooked when considering high performance upgrades. Performance engineered, multi-layer bearings generate less heat than normal bearings by reducing friction. Cosworth Race bearing sets feature a unique combination of design, metallurgy and engineering to deliver performance in extreme conditions. Cosworth Race bearings sets are available in 3 sizes to accommodate most applications.

Specifications

High strength overlay plate with reduced thickness for better oil control and less friction
Hardened steel backing on all connecting rod bearings
Increased crush and elimination of flash plating
3/4 grooving on Main Bearings providing optimum oil supply
Tight consistent wall tolerances
Oversize chamfers where applicable
Flash plating eliminated for improved heat transfer
Tested to over 1000 horsepower

Size Options

Size 0 provides .025mm or .001″ less oil clearance than our size 1 bearing and should be used when less clearance is required
Size 1 bearings are a nominal standard size and are used for most applications
Size 2 bearings feature an additional .025mm or .001″ clearance and should be used when extra clearance is required.

Engine bearings are one of the most vital components within an engine and are often overlooked when considering high performance upgrades. Performance engineered, multi-layer bearings generate less heat than normal bearings by reducing friction. Cosworth race bearing sets feature unique combinations of design, metallurgy and engineering to deliver performance in extreme conditions. Cosworth race bearings sets are available in three sizes to accommodate most applications.

Engineered with the following features:

High strength overlay plate with reduced thickness for better oil control and less friction
Hardened steel backing on all connecting rod bearings
Increased crush for better retention
3/4 grooving on main bearings providing optimum oil supply
Tight consistent wall tolerances
Oversize chamfers where applicable
Flash plating eliminated for improved heat transfer
Tested to over 1000 horsepower!

Our bearings are available in 3 sizes: 0 , 1, 2. We do not offer undersized bearings for ground crankshafts.

Size 1 is what we used to call “STD”
Size 2 is what we used to call “RACE”
Size 0 provides .025mm or .001″ less oil clearance than our size 1 bearing
Size 2 provides .025mm or .001″ more oil clearance than our size 1 bearing

Bearing half shells can be mixed and match to provide the incremental changes in oil clearance However it is imperative that bearing clearances are measured before selecting the appropriate bearing size.
